Structure
Shell: RCC framed structure with masonry partitions. Floor to floor height will be 10'.
Masonry: AAC/Solid-block masonry of 200 mm thickness for exterior walls and AAC/solid-block masonry of 100 mm & 150 mm thickness for interior walls.
Plastering: 18 mm thick double coat waterproof plastering for external walls. 12 mm thick single coat plastering for internal walls.
Flooring and Dado
Living, Dining & Kitchen: 800X800 mm vitrified tile flooring.
Utility: 300X300mm anti skid ceramic tile flooring.
Bedrooms: 600X600mm vitrified tile flooring.
Bathrooms: 300X300mm anti skid ceramic tile flooring and 300X450mm wall tiles upto door top.
Balconies/Sit-outs: 600×600mm anti skid ceramic tile flooring.
Parking Floor: Vacuum Dewatered flooring/Indian Patent Stone flooring/Parking Tiles/Cement Flooring.
Terrace Flooring: IPC flooring
Makes: Qtone, Metro, REX or Equivalent Make
Sanitary Fixtures
Water Closets: Wall mounted western style, porcelain EWC of reputed make will be provided in all bathrooms.
Overhead Showers: All bathrooms except the bathroom of multiple purpose room, will be provided with overhead showers of reputed make.
Wash Basins: Porcelain wash basins of reputed brands will be provided in all bathrooms. All basins and CP bottle traps of standard make will be provided.
Kitchen Sink: Stainless steel sink of reputed make will be provided.
Faucets: All Faucets will be of CP, heavy body metal fittings of reputed manufacture.
Washing Machine Point: One cold water inlet and drainage outlet will be provided in the Utility.
Plumbing: All water supply lines will be of CPVC & drainage lines will be of PVC pipes.
Makes: Sanitary fixtures - Kohler, Hindware, American Standard or Equivalent.
Doors and Windows
Door Height: All doors will be 7' height above finished floor level.
Frames: Main Door Frame will be of Teak Wood and rest All door frames will be of hardwood.
Shutters: All doors will be solid core flush (block board) shutters with paneled decorative veneers with polished finish or factory pressed laminate shutters or molded doors with painted finish.
Glazing: 5 mm thick float glass with provision for mosquito mesh.
Hardware: All hardware will be of stainless steel with a brushed finish. The main door will be provided with a latch of reputed make. All other Doors will be provided with door bolts and a mortise/tubular/cylindrical lock.
Windows Make: Fenstech, NCL Veka, Kommerling, Ashrith or Equivalent Make
Paintings
Interior Paint: All interior paint with two coats of lupum, one coat of primer and two coats of plastic emulsion paint as per architect's color scheme.
Exterior Paint: Two coats of exterior grade lupum and two coats of exterior grade acrylic emulsion with one coat of primer as per architect's color scheme.
Staircase Handrail: Will be of stainless steel or MS or Glass or a combination of the above as per the Architect's design.
Makes: Birla Putty, Asian paints, Berger, Nerolac, Techno paint or Equivalent Make.
ELECTRICAL
Wiring: All wiring will be of reputed make FRLS wires and cables, concealed in 25 mm diameter. The wiring for the 15 amp point will be 1100 grade 3/20 copper wire which is sufficient for equipment capacity of upto 5.0 kW. The wiring for 5 amp point will be of 3/22 rating which will be sufficient for wet grinder/ mixer/ shaver/refrigerator/washing machine and other appliances of capacity up to 1100W.
Switches: All switches will be of reputed make. Sockets will be provided in living, dining and bedrooms. In addition to basic lighting and fan controls, the following number of sockets will be provided in various rooms:
Living/Dining: 4 nos-5 amp switch & socket, 1 no-15 amp switch and socket.
Kitchen: 3 nos-5 amp switch & socket, 3 nos-15 amp switch and socket.
Utility: 1 no-5 amp switch & socket, 2 nos-15 amp switch and socket.
Master Bedroom: 4 nos-5 amp switch & socket.
Other Bedrooms: 3 nos-5 amp switch & socket.
Bathrooms: 1 no-5 amp switch & socket.
Terrace: 1 no-5 amp switch & socket, 2 nos-15 amp switch and socket.
Geyser: Provision of geyser along with switch & socket in all toilets.
Exhaust: Provision of exhaust along with switch & socket in kitchen and toilets.
Common Area Lighting: Solar powered light posts with lamp fittings.
Makes: Conduits: Sudhakar, Precision, Avon plast, Poly cab or Equivalent make.
COMMUNICATION SYSTEM
Telephone Point: One telephone point each will be provided in the living room and master bedroom.
Internet/Cable: Conduit will be provided at designated location as provision for laying cable.
TV Cable: Conduit will be provided in the living room and master bedroom as provision for laying cable.
SECURITY SYSTEM
Solar Powered Fence: Will be provided for the total compound wall. Surveillance cameras will be provided at main security and entry/exit gates.
Internal Compound Wall: 5 feet height behind each villa.
UTILITIES AND SERVICES
Back-up Power: To the extent of 1 KVA will be provided to individual units and also to common area lighting, pumps and motors. The generators will be provided along with an automatic change over switch.
Solar Water Heater: Each unit will be provided with a solar water heater of adequate capacity.
Sewage Treatment Plant: STP of adequate capacity will be provided.
Water Treatment Plant: Fully treated water will be made available through a specialized water softening and purification plant.
Water Supply: Water is supplied through an underground piping system from a treated water sump.
Rain Water Harvesting: As per IGBC and HMDA norms.
Road Network: As per HMDA norms.
FACILITIES AND AMENITIES
Clubhouse: Banquet Hall/Cafeteria for parties or functions or a multi-purpose venue, Indoor gaming room, 2 no Suite rooms are provided for the guests. Open Theatre/miltipurpose Area is also provided.
Club House Area: 34850 Sq.ft.
Swimming Pool: 50m x 9m x 1.5m depth, include 5m x 9m paddle pool area for kids, with changing rooms are provided.
Gym: Will be provided with commercial low impact treadmill, total body elliptical fitness cross trainer, upright cycle, 4 station multi-gym, multipurpose bench and dumbbell rack, Smith machine, power rack and machine fly. Open Air Gym is also provided.
Outdoor Sporting Facilities: Basketball hoop, Volley Ball Court, Badminton court, Cricket Practice Net, Children's Play Area, Walking or Jogging Track and Skating Ring
Shopping Facilities: Provision for commercial places such as pharmacy, grocery stores or super markets
LANDSCAPING
Soil: A mixture of good quality red soil and sand mixed with compost will serve as the base layer for landscaping.
Soft Landscaping: Grass, shrubs, bamboo and easy maintenance plants will be provided.
