STRUCTURE
RCC Framed Structure designed for Seismic Zone 3, Foundation Type - Isolated & Raft Antitermite at Plinth Level
Steel Grade-Fe550/Fe550D from Kamatchi/Tulsyan; RMC as per design Mix Masonry works - Solid Block (Outer wall of 8" & Inner walls of 4")
Ceiling - Putty Work
Clear Height - 9'6" Floor to Floor
OTS Area covered with Polycarbonate sheets
FLOORING
Glazed Vitrified Tile for all rooms with KAJARIA or equivalent size of 2'X4' for Living/Dining/Bedroom and MATT 2'X4' for Kitchen & Utility
Granite Flooring in all Common Areas & Staircase
Balcony with size 1'X 1' Vitrified Matt Finish Tile
Toilet: Matt finish vitrified tile up to the false ceiling level
KITCHEN
Open Kitchen
Matt finish vitrified Dado tile - laid 2 feet above the counter
Single bowl 10" Depth stainless steel sink of reputed brand
Provision for RO point, Exhaust fan and Chimney
Provision for washing machine & Dish Washer in utility area
Power point for Chimney, Refrigerator, Microwave oven, Mixer / grinder
TOILETS
Toilets: Comes with wall mounted EWC of Kerovit / Kohler or equivalent
Provision for health faucet in all toilets
CP fittings, hot and cold-water mixer unit for showers (Kohler or equivalent)
Wall mounted washbasin in all toilets (Kerovit or equivalent)
Wall Hung basin in dining area
DOORS & WINDOWS
Main Entrance Door: Size - 4' X 8' Double side veneered 40mm thick flush door with Teak frame and Melamine polished finish
Bedroom Door: Size-3'X7'-Wooden frame with 35mm thick shutter with two side Laminate Finish and polished frames
Toilet Door: Size -2'6"X7"-Wooden frame with 32mm thick shutter with two side Laminate Finish and polished frames
Locks, Tower Bolts & Handles from Godrej / Yale or Equivalent
Aluminium windows for all common areas
French Door: UPVC with clear Toughened glass
Window: UPVC with 6mm Toughened glass and MS Grill
UPVC with frosted glass in toilet ventilators (openable Type) with an exhaust fan provision
PAINT FINISHES
Internal Walls and Ceiling: Smooth putty finish with 2 coats of acrylic emulsion paint of reputed brand over one coat of primer
External Walls: Textured finish with 2 coats of weatherproof exterior emulsion paint of reputed brand
MS Grill: Enamel paint over one coat of Zinc chromate primer
ELECTRICAL
Concealed insulated fire retard low smoke wiring (Fybros/Anchor or equivalent) 3-phase electric supply with MCB & RCCB
Provision for Telephone points in living area
Provision for Internet Connection in living and master bedroom
Modular switches (Litaski / Great White or equivalent)
Integrated DTH system using Triax Sat Wave System
Miniature Circuit Breaker (MCB) for each room shall be provided through the main distribution box set-up in each flat
Provision for horizontal geyser, exhaust fan in all bathrooms
Split AC provision for living, dining and all bedrooms with Concealed Drain Provision
One Residual Current Circuit Breaker (RCCB) with 30m A sensitivity in each flat distribution box
PLUMBING
CPVC concealed water lines for internal lines from Astral or equivalent
UPVC/PVC pipes for external lines from Astral or equivalent
Bore wells/metro water, underground and overhead storage tanks (of suitable capacity) with pumps
UG sump capacity of 10000 Ltrs for Metro: 93000 Ltrs for Borewell raw water & Filtered water with partition
POWER BACK UP
D.G. Set backup with AMF for all common amenities including clubhouse, lifts, common lighting, motor and pump
Apartment Power Backup with Load Limiter: 3BHK - 1.5KVA, 2BHK - 1.5KVA
