STRUCTURE
RCC framed structure with RCC slabs & beams system
SUPER STRUCTURE
External walls in brick masonry 9" thick using Solid Fly Ash Blocks/light weight bricks/AAC blocks
Internal walls in brick masonry 4½" thick using Solid Fly Ash Blocks/light weight bricks/AAC blocks
WALL FINISHES
Internal Walls Double coat plastering/Punning with roller applied high grade plastic emulsion of Asian paints or equivalent make over smoothly prepared surface with putty.
External Walls High grade Weather proof Asian paint or equivalent on textured finish
WATER PROOFING
Water proofing will be done with Fosroc/MYK/Bostic Brush bond waterproofing chemical in all toilets, terraces, sit outs & balconies and other wet areas if any
JOINERY
FRAMES
Main door 4' width (height 8') frame in solid teak wood with architraves finished with Melamine polish
Internal door frames (height 8') in solid wood frames with architraves finished with Melamine polish
SHUTTERS
Main door: 8' high Solid teak paneled shutter with melamine polish
Bedroom doors: 8' high Flush shutters with teak/oak veneer finished with melamine polish
Toilets & Utility door: Flush shutter finished with paint / laminate
HARDWARE
Door Hinges and Tower bolts in SS/ Brass SS Coated of Quba or equivalent make
WINDOWS
Windows Double Track Sliding Powder Coated Aluminum windows with 5mm/8mm glass to address noise reduction along with standard hardware.
FLOORING & SKIRTING
Foyer, Drawing, Living, Dinning: Large format vitrifies tiles 800mmx800mm
Bedrooms: Vitrified tiles of Kajaria/Simpolo/RAK or equivalent with 600mmx600 mm size
Kitchen: 2'x2' Anti-skid: Vitrified tiles of Kajaria/Simpolo/RAK or equivalent
Sit outs: 2 X 2' Antiskid Vitrified Tiles of Kajaria/Simpolo/RAK
Toilets & Utility Flooring: 1' X 1' Antiskid ceramic/vitrified Tiles of Kajaria/Simpolo/RAK or equivalent make. Natural stone in shower areas
Parking Area: Vacuum Dewatered flooring with drain channel
Staircase: Natural stone (Kota/Tandoor) or Concrete floor
Corridor & lift lobby flooring and lift claddings: Polished Granite/tiles
DADO
Toilets: Dado up to 8' (lintel Height) in glazed ceramic/vitrified tiles Kajaria/Simpolo/RAK or equivalent make size 500x600
Utility: Dado upto 4' in glazed ceramic/vitrified tiles of Kajaria/Simpolo/RAK or equivalent 300x600 mm size
ELECTRICAL FIXTURES & CABLES
Light points: one light point for every 100 sft of built up area for each unit. Two way light points one each in each bed room, one light point for every 500 slt of garden area
Fan points: One point each in drawing, living, all bedrooms, dining, kitchen Exhaust fan points in all toilets & kitchen
Bell: One call bell point with buzzer outlet in drawing
POWER SOCKETS
5AMPS: 2 no's 5amps in each bed rooms, 1 no 5 amp in each toilet, two each in dining and drawing, 3nos in kitchen (for cook top, chimney and RO unit)
15 AMPS: 1 in each toilet for geysers, 6 no's for refrigerator, washing machine, oven and other kitchen appliances in Kitchen and Utility
20 AMPS: Split type AC'S points in all bedrooms, dining, living and drawing
TV CABLE OUTLETS
Conduit for TV Cable in living, drawing, master bedroom
Internet: Internet cable conduit provision in living room
Earthling: Multi strand copper wire for earthling by means of loop system. Separate earthling for transformer, DG set and lighting protection
Distribution Boards with ELCB's and MCB's of MDS Legrand/ABB/Havells or equivalent make
Switches: Legrand/Schneider/Panasonic or equivalent make
Cables: Concealed Copper Wiring o Polycab/Finolex or Equivalent
Power Backup: 100% Power Backup for common areas and all flats
Lift: 4 no's 8 passenger capacity + 1 no 19 passenger capacity goods lift of Johnson or ThyssenKrupp..
BATH FIXTURES & PLUMBING
SANITARY FIXTURES
Washbasins: Bedroom toilet wash basins of TOTO/Grohe or equivalent
EWC: wall mounted EWC of TOTO/Grohe or equivalent with concealed flush tank, health faucet and angle stopcocks
CP FIXTURES/FAUCETS
Basin Mixers: Grohe/Bravat/Vitra Basin mixer for hot and cold water & angle stopcocks
Shower: concealed single lever diverter for hot and cold water, over head shower & spout of Grohe/Bravat/Vitra or Equivalent
KITCHEN BOWLS
Kitchen: single bowl with drain board of size 40"x20" of Nirali/FRANKE make or equivalent with wall mounted sink cock, angle stopcocks below counter.
Utility: Double bowl without drain board of size 20"x20" of Nirali/FRANKE make or equivalent with wall mounted sink cock, angle stopcocks below counter.
Necessary plumbing provision shall be made for washing machine.
GEYSER: Provision for Geyser's in all Toilets & Kitchen utility
WSP & STP
Domestic Water made available through an exclusive Water Treatment Plant (Not RO Plant)
Sewage Treatment plant of adequate capacity as per norms will be provided inside the project, treated sewage water will be used for the landscaping and flushing purpose.
Rain Water Harvesting at regular intervals provided for recharging ground water levels as per the norms.
SERVICES
Water Supply: water supply shall be means of Gravity system from tank. Supply of water shall be from municipal main and bore well. Supply from bore well shall be treated as requirement. Supply lines CPVC of Prince / Astral/Sudhakar make or equivalent.
Drainage: Internal and external drainage lines in GRADE 'B' UPVC of Prince or Astral make or equivalent.
Carwash area: Space for common carwash area with recycled water.
SECURITY
Sophisticated round-the-clock security/Surveillance System.
7' high Compound wall with 3' high Solar fencing above
Surveillance cameras at main entrance and other key locations.
FIRE & SAFETY
Fire hydrant and fire sprinkler system in all floors and basements as per NBC Norms.
Fire alarm and Public Address system in all floors and parking areas (basements) as per NBC Norms.
