Structure
Framed Structure
RCC framed structure resistant to wind and earthquake (Zone-2)
Super Structure
Solid Cement Concrete Blocks for External and Internal walls
Plastering
Internal: Gypsum/Cement sand plaster for walls and ceilings
External: Double coat plaster for RCC and masonry surfaces
Doors and Windows
Main Door
Frames: Teak wood with melamine polish
Shutter: Flush shutter with veneer on both sides with melamine polish
Internal Doors
Frames: Engineered wood
Shutter: Flush shutter with veneer on both sides with melamine polish
Hardware
Hardware of reputed make
French Doors
Aluminum/UPVC sliding window with clear glass and provision for mosquito mesh
Windows
Aluminum/UPVC sliding door with clear glass and with mosquito mesh for sliding Windows
Lift
Structural provision will be provided (Purchase of Lift, earth pit, cladding etc., is at Client scope only)
Plumbing and Sanitary
All Bathrooms
Polished Chrome (CP) and sanitaryware fixtures of Villeroy & Boch or Vitra make
Vanity Type Wash Basin with Hot & Cold mixer
Shower single lever diverter with Spout & Overhead Shower
Electrical
Concealed copper wiring of reputed make
Power Socket for ACs in the villa
Heat Pump shall be provided with hot water connection in Four/Five Bedroom Washrooms
Power socket for cooking range, chimney/exhaust fan, refrigerator, microwave oven, mixer/grinder & water purifier in kitchen
Power socket for washing machine in utility area
Three-phase supply for each unit with individual dual source energy meter
Miniature Circuit Breakers (MCB) for each distribution board of reputed make
Modular switch boards of reputed make
TV/Telephone
Fibre-to-the-home for Internet, telephone & Intercom
Provision for DTH & TV services in all Bedrooms, living room, family lounge & multipurpose hall
Provision for Telephone in Drawing Room
Flooring
Drawing/Living/Dining/Family Lounge/All Bedrooms /Kitchen and Home Theatre: 1600 X 900 mm Vitrified Tiles of reputed make
Bathrooms: Anti-skid Vitrified Tiles of reputed make
Terrace: Anti-skid Vitrified Tiles of reputed make
Parking Area: Full body Vitrified Tiles of reputed make
Staircase: Granite or equivalent make
Dado
Bathrooms: Polished Glazed Vitrified Tiles (PGVT) / Glazed Vitrified Tiles (GVT) of reputed make up to lintel level
Utility/Wash Area: Polished Glazed Vitrified Tiles (PGVT) / Glazed Vitrified Tiles (GVT) of reputed make up to sill level
Railing
Staircase & Balconies: Internal staircase railing will be of SS and First floor front side elevation balcony railing will be of Glass and the remaining balconies with glass
Kitchen
Kitchen ready to receive Modular Unit
Counter, Dado, Sink and Taps are not included in the scope of work
Provision for electrical and plumbing points for sink and water purifier
Power Plug for Chimney, Refrigerator, Micro Oven/Mixer/Grinder and Cooking Range/Rice Cooker
Painting
External: Texture/smooth paint with two coats of weather shield exterior emulsion. Tile cladding as per facade detail
Internal: Two coats of emulsion paint over smooth putty finish
Water Proofing
Toilets and Open Terrace
Back-up for Power
DG Back up for the common services and for each villa up to 8KVA load
Billing System
Prepaid Billing System for electricity, DG, Water & Maintenance
Security System
Sophisticated Round the Clock Security System
Solar fencing throughout the boundary
Intercom facility to all the units connecting to main security
Water Supply
Centralised water distribution by hydro-pneumatic system for all villas with individual water meters for each villa
WTP & STP
Water Treatment Plant only for bore-well water supply
Sewage Treatment Plant of adequate capacity as per norms will be provided inside the project. Treated sewage water will be used for the landscaping purpose
Rainwater harvesting provided for recharging ground water levels
