Structure
RCC framed structure (with M20 grade of concrete and steel with TMT ISI brand).
Super Structure
All external walls are 9" red bricks blocks and internal walls 4" thick red bricks blocks.
Plastering
Internal: Single coat cement plaster for walls and ceiling with smooth/sponge finish.
External: Double coat plaster for external walls with waterproof compound mixed for RCC and masonry surfaces.
Toilets: Glazed vitrified/ceramic tile Dados up to 7' height with 2'0" x 1'0". Flooring anti-skid tile 1'0" x 1'0".
Utility: Ceramic/vitrified tile Dado up to 4' height.
Attached Balconies: Anti-skid tiles 2'0" x 2'0".
Parking: Vitrified tiles/tandur or equivalent stone.
Painting
External: Texture finish with two coats of exterior emulsion of Asian/Berger/Techno/AKZO or equivalent make emulsion.
Internal: One coat of primer and 2 coats of Asian/Berger/Techno/AKZO or equivalent emulsion paint over two coats of putty with smooth finish.
Kitchen/Utility
Water supply point for municipal and raw water connections at one point (sink) with provision for fixing of water purifier, exhaust fan/chimney. No kitchen platform, no sink provided.
TV, Internet & Telephone
TV point in living, MBR, Lounge, and Home theatre.
Internet provision at one point in each floor.
Telephone point in living, MBR, Lounge.
Wood Work
Main Door: Imported Teak wood/hard wood frame with PU polish. Shutter with both sides decorative veneer with PU polish.
Internal Doors: Imported Teak wood/hardwood frames with PU polish. Flush shutters both sides decorative veneer with PU polish. Toilet/utility door shutter one side decorative veneer polish and other side with Laminate/enamel painting.
Power/Generator Backup
100% power backup for common amenities, common areas, common parking areas, pressure pumps, and street lights, etc., by providing Auto start, soundproof generator of caterpillar, Kirloskar, JCB or approved make with auto change over switches.
Water Supply
Borewell water supply will be through Hydro pneumatic pumps from the storage sump to the overhead tank of 1000 liters capacity provided on the terrace of each villa.
Provision of a dedicated water supply line from the main gate to sump for HMWSSB line connection will be provided. From the sump to kitchen supply will be through a hydropneumatic pump for municipal line.
Windows / French Doors
UPVC windows and sliding doors with clear glass and mosquito mesh of reputed make.
Bathroom
Shower single lever diverter with spout & overhead shower with geyser provision. Wall-mounted/floor-mounted EWCs with health faucets and wash hand basins in all bathrooms with best quality Polished Chrome (CP) and sanitaryware fixtures of HINDWARE/JAGUAR/KOHLER or equivalent make.
Electrical
Concealed copper wiring (Finolex / Polycab / Havels or equivalent make) in conduits. Power outlets for AC provisions in all bedrooms, home theatre, drawing/living, and geyser provisions in all toilets.
Power points for cooking range, chimney, refrigerator, microwave oven, Mixer/grinder in the kitchen, and for washing machine in the utility area.
Inverter wiring for one fan and lighting in all rooms and kitchen.
Three-phase supply for each unit with 5 KW and provision of individual meter and DBs with MCBs (Honeywell / Havels or equivalent make).
All electrical Modular switches are of Honeywell / Havels / Anchor or equivalent make.
Security System
24 hrs. Surveillance and Security facility.
Solar fencing throughout the boundary.
Security Surveillance Cameras at appropriate community locations.
Main entrance will be provided with access-controlled boom barrier and security room.
Compound Wall
Common compound wall for villas on three sides.
Staircase
Granite steps with premium grade stainless steel railing for the internal staircase.
Waterproofing
All toilets, open terraces, and balconies waterproofing will be done as per standard procedure.
