Shelter Tulip

FOUNDATION:

Framed Structure column Foundation with Plinth beam

SUPER STRUCTURE:

All external and few internal Dividing walls will be 9" and 4 1?2" thick Brick Work.

FLOORING:

Stilt Floor finished floor level will be 2.6" ft height from the Existing road level & Ramp; Car Parking ceiling height 8'6"

LIVING:

2x2 Vertified Tiles DINING, KITCHEN ALL OTHER ROOMS: 2x2 Vertifled Tiles, also Polished Granite Kitchen Top with Stainless Steel Sink. One wash basin in the dining Hall, and above kitchen top wall tiles Dadoing upto 3'0" hight.

TOILETS:

Glazed tiles dadoing upto 7'0" high (13" x 10") anti skid plain colour

WOOD WORK:

Main door will have complete teak Wood Panel door. All other doors will be Country wood flush Windows and ventilators will have UPVC windows with Grill

ELECTRICAL:

Concealed Wiring in PVC conduits Anchor or equal Ent Switches and Breaker and DB box Standard or Equal Ent, 3 Phase Power Supply, Ample lighting and Power outlets With required Fan provisions, Light Points in ceiling for common areas With Kundan cables, A.C point will be provided in all bed-rooms.

EXHAUST FAN:

One exhaust fan point will be Provided at the kitchen & Toilet.

PLUMBING :

White colour EWC-S trap Parryware or equalent white washbasins, C.P. Fitting jaguar Or equal Ent S.S/Granite Sink with Long body taps.

PAINTING:

Ceiling Painting two coats Putty With emulsion for interior walls Asian paints or equalent, Exterior Walls painted with ACE Emulsion, Wood Polish for Main Door and Enamel Paints for other doors and MS grill and main door gates.

COMMON AMENITIES:

Overhead tank will be constructed For well/bore /sump. One MS gate will Be provided, light points for the Common area around the building and The stair case landing, terrace and Passage will be provided.

Lift will be provided. (i.e 4 passengersLift) CCTV Camera will be Provided.

WATER:

One Bore and well will be provided

COMPOUND WALL:

5'-0" above foundation level with MS gates.
