Himayam Annapoorna

Structure:

Reinforced cement concrete framed structure with isolated column footings connected with tie beams with earthquake resistance design and using TATA steel or I steel and first grade cements like L&T, Coromandel or Birla.

Brickwork:

Good quality brick walls of 9" thick on outer walls and 4 1/2" thick partition walls and plastered with good finish.

Woodwork:

All doors and window are of good quality teak wood and windows will have solid square MS grills. Main door solid teakwood panelled door shutter with teakwood polish.

Electrical:

Three phase power connection with phase changer 20 Ams power plugs for all AC supply in all rooms and Living Hall. 15 Ams for geyser in Toilets and enough power points in kitchen, rooms and hall for all purposes. Concealed cables for TV connections and 3 pair telephone lines in Living and Master bedroom. Modular switches of premium quality Legrand switches and ISI brand wires will be used with standard circuit breakers and load distribution.

Flooring:

Living, Dining Marble or granite flooring Rs.125- per Sq. ft. and other areas Marbonite or fully vitrified tiles flooring of standard brands like Johnson, Somany, Asian or Nitco Rs.70- per Sq.ft. and toilets concept series good quality glazed tiles upto 7' height or upto ceiling height.

Kitchen:

Stainless steel or granite moulded sink with granite counter top.

Toilets:

Jaguar CP fittings, Parryware or Hindware sanitary fittings with concealed water tanks.

Painting:

Internal walls two coats of Birla wall putty, one coat of primer and two coats of premium interior emulsion. MS grills and Balcony grills are painted with enamel paint. External paint premium quality weather proof Apex paint.

Carpark:

Carpark area and pathways all round the building will be provided non-skid concrete designed tiles of Nitco or branded company concrete tiles at 2' above road level.

Lift:

OTIS or Johnson or Emperor lift. Front walls in the lobby will be provided with granite stones or designed decorative tiles for easy maintenance and for good looking. Power backup generator for lift, common lighting, water pump.

Common Lobbies and Staircase:

Lobbies flooring will be provided with marble or granite flooring and staircase steps are marble or granite steps with non-skid grooves.

Water:

One well and one deep borewell for ground water and 16,000 litres capacity RCC underground sump for Corporation water. Two RCC overhead tanks depend upon water quality one water treatment plant.

Rainwater Harvesting:

We will do proper rain water harvesting pit near borewell or well filled with gravel and brick bat and covered with concrete slabs with air vent.

Weathering Course:

Open terrace we will do water proofing with grano flooring and above that brick bat and lime with Jagari and kadukka for heat resistant above that good quality Kerala pressed tiles. Possible extent roof garden and few sitting benches and rust proof cloth lines for drying. Proper lighting arrangements for any small evening functions or get together.

Elevation:

Open terrace we will do water proofing with grano flooring and above that brick bat and lime with Jagari and kadukka for heat resistant above that good quality Kerala pressed tiles. Possible extent roof garden and few sitting benches and rust proof cloth lines for drying. Proper lighting arrangements for any small evening functions or get together.

Security:

Security room with sloping roof with red tiles and intercom facility for all flats. Common toilets for security, servants and drivers.

Landscaping:

Landscaping All round the building good plantation with possible extent green grass lawn.

Power backup Generator and Terrace roof Garden and perculated designed roof for small functions and meetings.
