Casagrand Palm Springs

STRUCTURE

Structural System : RCC framed structure designed for seismic compliant (Zone - 3)

Masonry : 200mm for external walls & 100mm for internal walls

Floor- floor height (incl. slab) : Will be maintained at 2950 mm

WALL FINISH

Internal walls : Finished with 2 coats of putty, 1 coat of primer & 2 coats of premium emulsion

Ceiling : Finished with 2 coats of putty, 1 coat of primer & 2 coats of Tractor emulsion

Exterior walls : Exterior faces of the building finished with 1 coat of primer & 2 coats of exterior emulsion paint with colour as per architect’s design

Bathroom : Ceramic tile up to 2250mm height of size 300x600mm & above false ceiling will be finished with a coat of primer

Kitchen : Ceramic wall tile of size 600x600mm for a height of 600mm above the counter top finished level

Bathroom ceiling : Grid type false ceiling

FLOOR FINISH WITH SKIRTING

Foyer, Living, Dining, Bedrooms, Kitchen & Utility : Vitrified tiles of size 600x1200mm

Bathroom : Anti-skid ceramic tiles of size 300x300mm

Balcony : Anti-skid ceramic tiles of size 600x600mm

Private open terrace (if applicable) : Pressed tiles finish

JOINERY

Wide and fancy main door of size 1050 x 2100mm with veneer finish and a designer architrave

Ironmongeries like digital door lock system of yale or equivalent lock, tower bolts, door viewer, safety latch, magnetic catcher, etc

Good quality door of size 900 X 2100mm with laminated shutter on both sides

Ironmongeries like Godrej or equivalent lock, tower bolt, magnetic catcher, door bush, etc.

Good quality door of size 750 X 2100mm with laminated shutter on both sides with waterproofing on inner sides

Ironmongeries like one side coin & thumb turn lock of Godrej / equivalent without key, door bush, tower bolt, etc.

WINDOWS

Windows : Aluminium powder coated windows with sliding shutter with see through plain glass and MS grill on inner side (wherever applicable)

French Doors: Aluminium powder coated frame and doors with toughened glass without grill

Ventilators : Aluminium powder coated frame of fixed louvered / openable shutter

KITCHEN & DINING

Kitchen : Platform will be finished with granite slab which is 600mm wide and at a height of 850mm from the finished floor level

Electrical point : For chimney / hob & water purifier

CP fitting : American Standard / Kohler / equivalent will be provided

Sink : Single bowl SS sink with drainboard

Dining : Granite counter with counter top washbasin

BALCONY

Handrail : MS handrail as per architect’s design

Cloth drying provision : Cloth drying hanger provided in balcony

BATHROOMS

Sanitary fixture : American Standard / Kohler / equivalent will be provided

CP fittings : American Standard / Kohler / equivalent will be provided

Attached bathroom : Wall mounted WC with cistern, health faucet, single lever diverter with rain shower, granite counter with counter top washbasin

Common bathroom : Wall mounted WC with cistern, health faucet, single lever diverter with overhead shower of wall hung washbasin.

ELECTRICAL POINTS

Power supply : 3-phase power supply connection

Safety device : MCB & RCCB (Residual current circuit breaker)

Switches & sockets : Modular box & modular switches & sockets of Schneider or equivalent will be provided

Wires : Fire Retardant Low Smoke (FRLS) copper wire of a quality BIS brand Polycab or equivalent will be provided

TV : Point in living & in any one bedroom and provision in other bedrooms

Data & USB : Point in living & in any one bedroom

Split- air conditioner : Points will be given in living / dining and in all bedrooms

Foot lamp : Provision in all bedrooms

Exhaust fan : Point will be given in all bathrooms

Geyser : Point will be given in all bathrooms

Back-up : 750W for 3 BHK, 600W for 2 BHK
