Bhaggyam Anugraha

Type of Construction

RCC framed structure with 9” Brick work and 4 1/2? Brick work. Walls to be plastered with Cement plaster.

Loft

Bedroom : RCC loft at a height of 7’0” from floor level and with a width of 2’0”.

Kitchen : RCC loft at a height of 7’0” from floor level and with a width of 2’0.

Platforms

Kitchen : Coloured granite platform at height of 2’8” from floor level with Carysil/equivalent make with single bowl sink with single drain board.

Toilet : 2’0” width Granite Counter Slab for Wash Basin.

Utility : Coloured granite platform with stainless steel sink. Provision for Dishwasher, Washing Machine and Dryer will be provided.

Flooring

Living, Dining areas : Branded tiles include skirting for all habitable rooms. Italian / Indian Marble.

Bedrooms : Vitrified tiles Kajaria or equivalent make.

Balcony : Vitrified tiles Kajaria or equivalent make.

Kitchen : Vitrified tiles Kajaria or equivalent make.

Toilets : Pastel/Soft coloured anti-skid ceramic tiles Kajaria or equivalent make.

Living, Dining areas : Italian Marble – Rolex Beige / equivalent.

Bedrooms : 4’0? x 2’0? Vitrified tiles of Kajaria/equivalent make.

Balcony : 4’0? x 2’0? Vitrified tiles of Kajaria/equivalent make.

Kitchen : 4’0? x 2’0? Vitrified tiles of Kajaria/equivalent make.

Toilets : 2’0? x2’0? Pastel/Soft coloured anti skid ceramic tiles of Kajaria/equivalent make to full height.

Door

Main Door : Teak Wood frame with Teak wood Panelled shutter. With Godrej lock and antique finish Tower bolts, brass hinges and fitted with rubber door stopper.

Other Doors : Treated Wood frame with Flush shutter with veneer finish and melaminine polish fitted with antique finished brass Tower bolts, brass hinges, and antique finished brass door stopper.

Toilet doors : Treated Wood frame with waterproof flush door shutter fitted with antique finished brass Tower bolts, brass hinges and fitted with antique finished brass door stopper.

Windows/Ventilato : UPVC window Fenesta or equivalent made with plain glass and MS bright bar grills, UPVC ventilators with fixed louvers as specified by the architect.

Baluster Rails : MS fabricated to design or as specified by the Architect, wherever required with Treated wood handrail.

Plumbing

Common Overhead tanks : Duct pipes of PVC True Bore / Finolex / equivalent make and terrace pipes of PVC.

Internal concealed : CPVC Pipe of Ashirvad / equivalent make.

Exposed Piping : PVC of Finolex / Trubore or equivalent make.

Wastewater line : PVC of Finolex / Trubore or equivalent make.

Tiling

Toilets : Pastel / Soft coloured glazed tiles up to a height of about 7’0” of Somany / equivalent make as specified by architect.

Above Kitchen platforms : Glazed tiles up to 2’0” above the platform with Johnson / Somany /equivalent make.

Utility : Ivory / White coloured glazed tiles of Johnson / Somany / equivalent make.

Sanitary ware

Bathroom : All sanitary ware will be white coloured. EWC of Kohler / equivalent make with concealed tank of Gebrit make. Ceramic Wash basin of Kohler / equivalent make.

Sanitary Fittings

All Toilets : Chromium Plated fittings of Jaguar / equivalent make. Single lever Divertor Jaguar / equivalent make. Over head shower of Jaguar / equivalent make.

Chromium plated low level tap and one concealed stop cock in each bathroom of Jaguar / equivalent make. A valve control in the main water intlet to toilets will be provided.

Electrical Supply & Wiring

Concealed wiring using Finolex / equivalent make suitable for 3PH. Supply.

Switches / plug points / light points / fan points / Main, Distribution Board with phase change over switch will be provided. Switches will be of Legrand/ equivalent make.

Wiring of 3/22 rating for 5A points and 7/20 for 15A points.

Provision of Split Air conditioner points in all bed rooms with additional provision for a computer point in Master bedroom.

Provision of power points (15A) for Fridge, grinder, microwave in the Kitchen.

Provision for exhaust fan and ceiling fans in Kitchen and all Toilets.

Telephone & Network Points

In living and all bedrooms.

Television Points

With cabling from common reception point terminating in the living room and all bedrooms capable of being linked up with cable operator’s signals.

Painting

Ceiling & Internal Walls : Two coats of Birla Cement Pasted Putty and one coat of Emulsion Primer and two Coats of Emulsion Paint of Asian paints/equivalent make.

External Walls : One coat of primer and two coats of External emulsion paint of Asian paints/equivalent make.

Main Door : Melamine Polishing.

Other Doors,Windows & Grills : Synthetic enamel painting.

Water proofing

Fosroc/equivalent make waterprofing chemical will be used in toilets, sitouts and all appropriate places.
