AK Chrysolite

FRAME STRUCTURE

R.C.C. framed Structure on Columns beams and slabs supported on independent foundation.

Structural designing done by well experienced structural consultant as per soil test report.

SUPER STRUCTURE

9” Brickworks - 1:5 ratios Cement Mortar with 1st quality table molded bricks used for external walls

4 ” walls - 1:3 ratios Cement Mortar with 8mm rods or 4 ”Steel plate every 3 layers of bricks for partition walls.

.LIVING / DINING

French window.

Electrical points

T.V. point 5AMPS - 1no

Telephone point 5AMPS - 1no.

Mobile Charge point.

Emergency lamp power point.

D B box with circuit breakers and 3 phase changeover switches.

Light point (3.nos),1Point 2WAY SWITCH

Fan point (2 nos)

Iron box power point provision 15AMPS - 1no.

Fridge power point provision 15AMPS - 1no.

Chandelier light point.

Calling Bell provision.

MASTER BEDROOM

R.C.C Loft 2'0" depth.

Electrical points.

Split A.C. provision.

Mobile charger power point provision. 5AMPS - 1no.

Foot lamp.

One tube light point with 2way control.

One fancy light point.

Fan point with 2 way control.

6.KITCHEN

Black Granite slab with beeding

One metro water and one bore water tap provision.

Wall tiles-Glassed tile with border up to 4’6” above the platform (Rs.40/-per sqft)

Electrical points.

One light points.

One fan points.

One Exhaust fan provision.

15AMPS power point (3nos).

5AMPS power point (2nos)

One water Purifier point 5AMPS - 1no.

TOILETS

Geyser power point 15AMPS - 1no.

Parryware Wash basin

Single Bedroom - Parryware IWC Orrisapan

Double Bedroom - Attached Toilet-Parryware Cascade model floor -

mounted (White colour), Common Toilet-IWC.

Walls Glassed tiles upto 7” height from floor level

Rs.40/-per Sqft).

Health faucet.

Exhaust fan provision & Ventilator with louver glasses.

PVC Door

Flooring - Anti-skid tiles.(12”x12”) (Rs.40/-per Sqft)

Chromium plated (Tap) fittings jaquar.

DOORS & WINDOWS

Main door - Teak wood frame with panel designed doors.

Main door - Eye viewer,Brass tower bolt, Bullet lock (Godrej locks), safety chain,

door magnet,modular handle.

Bedroom doors-Teak wood frame with designed door (both side enamel paint)

Toilet door - Teak wood frame with water proof door.

Teak wood frame with shutter pinned glass

FLOORING

Vertified Tiles (2’ x 2’) for all rooms (Rs.60/per sqft) Skirting for 4”

PAINTING

Interior wall and ceiling fully 2 coat of putty one coat of primer with 2 coats Premium Emulsion Painting.
